Canary Releases in Kubernetes

Canary releases are a strategy for deploying new features incrementally in Kubernetes. Instead of rolling out changes to all users at once, this approach allows you to direct a small percentage of traffic to a new version of your application while the rest continues to use the current stable version. This gradual rollout helps detect and address issues early without affecting the majority of users, reducing the risk of service disruptions.

In Kubernetes, implementing a canary release involves setting up mechanisms to control traffic distribution between different application versions. Tools like Istio and NGINX Ingress Controller enable fine-grained traffic management, allowing you to monitor the performance of the new version while maintaining a fallback to the stable version. This tutorial will guide you through the process of setting up a canary release strategy using Istio, starting from configuring your cluster to managing traffic splitting and handling rollouts or rollbacks. By the end of this tutorial, you’ll have the knowledge to implement safer and more efficient application updates in your Kubernetes environment.

Setting Up Your Kubernetes Cluster

Before you can implement a canary release strategy, it is essential to have a fully functioning Kubernetes cluster as your starting point. In this section, we will guide you through the process of setting up a cluster, installing the necessary tools, and deploying a sample application to work with later in this tutorial.

Provision a Kubernetes Cluster

There are multiple ways to create a Kubernetes cluster, depending on your environment and needs:

Cloud-based Managed Kubernetes Services: Use a managed service like Google Kubernetes Engine (GKE), Amazon Elastic Kubernetes Service (EKS), or Azure Kubernetes Service (AKS). These services handle most of the cluster management tasks, such as provisioning nodes and setting up control planes. Follow the provider's documentation to create a cluster in your preferred region.

Local Development Clusters: If you’re experimenting locally, tools like Minikube, Kind, or K3s are excellent options. For example, to create a cluster using Minikube, run:

minikube start

Bare-metal or Custom Cloud: You can also set up a Kubernetes cluster on bare-metal servers or VMs using tools like kubeadm or Rancher. This requires more manual configuration but offers complete control.

Once the cluster is provisioned, confirm its status:

kubectl cluster-info
kubectl get nodes

Install and Configure kubectl

kubectl is the Kubernetes command-line tool used to interact with your cluster. Install it on your local machine if it’s not already available. You can download the appropriate version from the Kubernetes documentation.

Verify the installation:

kubectl version --client

After installation, configure kubectl to connect to your cluster. If you’re using a managed service, follow their instructions to download the kubeconfig file and set it up:

kubectl config view
kubectl config get-contexts

Switch to the appropriate context for your cluster if needed:

kubectl config use-context <your-cluster-context>

Deploy a Sample Application

To implement a canary release strategy later, we need a running application in the cluster. Let’s start with a simple Nginx-based application:

Create a Deployment: The following YAML file defines a Kubernetes Deployment for a sample application. Save this as deployment.yaml.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
  labels:
    app: my-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: my-app
        image: nginx:1.19
        ports:
        - containerPort: 80

Create a Service: Expose the deployment via a Service. Add this to the same deployment.yaml file or create a separate service.yaml file:

apiVersion: v1
kind: Service
metadata:
  name: my-app
spec:
  selector:
    app: my-app
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  type: LoadBalancer

Apply the Configuration: Deploy the application to your cluster by applying the YAML file:

kubectl apply -f deployment.yaml
kubectl apply -f service.yaml

Verify the Deployment: Ensure that the pods and service are running correctly:

kubectl get pods
kubectl get svc

You should see the my-app pods running and the service exposing your application. If using a cloud provider, the service will automatically assign an external IP address.

Test the Application: Access the application by navigating to the external IP address of the service in your browser:

kubectl get svc my-app

Copy the external IP from the output and paste it into your browser. You should see the default Nginx welcome page.

Namespace Organization (Optional)

For better isolation and organization, you can deploy the application in a dedicated namespace:

kubectl create namespace canary-demo
kubectl apply -f deployment.yaml -n canary-demo
kubectl get pods -n canary-demo

You’ve set up a Kubernetes cluster with a running application. This serves as the foundation for implementing the canary release strategy.
